Key features
10-year Limited Warranty. Read about the terms in the Limited Warranty brochure.
The faucet insert has hard, durable ceramic discs that can handle the high friction that occurs when you change the temperature of the water.
The faucet functions two ways, so you can switch between a concentrated stream and hand shower just by pushing the buttons on the handle.
The handle holder is magnetic making it very easy to detach and attach the hand spray with only one hand. Washing and rinsing becomes very flexible and convenient.
Equipped with check valve to prevent back flow.
Designer
Good to know
Tested and certified according to applicable codes and standards including: ASME A112.18.1/CSA B125.1, NSF 61 and NSF 372.
This faucet is for use on high pressure water systems. Tested to work with a max. pressure of 10 bar (1000 kPa). Recommended working pressure range is 1.0 – 5.0 bar (100 kPa – 500 kPa).
If you are uncertain about the installation, contact a professional. The installation shall be made in accordance with valid local building and plumbing regulations.
To be mounted in a 1⅜" hole in a max. 2" thick sink/countertop.
Water and energy saving aerator (1.5 gal/min.) for high-pressure systems included.
Connection hoses with 9/16" connection included. Length: 13¾".
A tool is included that makes it easy to install the faucet in place.
Max. temperature hot water connection 80°C/176°F. Recommended temperature is 65°C/149°F.
Spare parts are available to prolong the life of your product. For more information, contact IKEA Customer Services at your IKEA store or IKEA.com.
Swivel spout: 360°.
Measurements
Assembled size
| Height: | 18 1/2 " |
Package size & weight
Do you take it home? Make sure it fits in your vehicle.
| Length: | 20 ¾ " |
| Width: | 11 ¼ " |
| Height: | 2 ¼ " |
| Weight Gross: | 5 lb 10 oz |
| Weight Net: | 4 lb 10 oz |
| Volume per package: | 0.32 cu.ft |
Materials
Care instructions
Do not use scouring-powder, steel wool, hard or sharp tools which can scratch the surface.
Wipe clean with a soft cloth dampened with water and a mild dish detergent or soap, if necessary.
Wipe dry with a clean cloth.
Technical information
| Type of faucet | |
| Applicable product standards | |
| Max. flow rate at 3 bar | |
| Max. static pressure | |
| Tested up to a max. static pressure | |
| Min. working pressure | |
| Recommended working pressure | |
| Max. hot water temperature | |
| Recommended hot water temperature | |
| Recommended cold water temperature | |
| Connection hoses length | |
| Hose connection size | |
| Max. worktop thickness | |
| Mounting hole measurement | |
| Strainer included | |
| Third party certified by |
Assembly instructions
Only the latest versions of these documents are available for download. This means that there may sometimes be differences between the documents you download and the versions that come with the product.
